Cub Cadet XT2 GX 54 D Garden Tractor

KING OF THE CADETS

Cub Cadet XT2 GX54 D Garden Tractor

 SPECIFICATIONS

Engine

AIR FILTER

Single element

CHARGING SYSTEM

15 amp regulated

CHOKE

Separate Choke

CYLINDERS

Twin

ENGINE BRAND

Kohler

ENGINE DISPLACEMENT

726cc

ENGINE MODEL

7000 Pro Performance

ENGINE MODEL NUMBER

KT740

ENGINE OIL CAPACITY

2.1 quarts US ( 2 L)

ENGINE START

Ignition Key

FUEL DELIVERY

Carburetor

FUEL GAUGE

No

FUEL TANK CAPACITY

3.0 gal. US (11.36 L)

GOVERNOR

Mechanical

ENGINE OUTPUT

24 HP

LUBRICATION

Fully pressurized

OIL FILTER

Yes

STARTER TYPE

Electric

 Cutting Deck

ANTI-SCALPING

4-gauge wheels

BLADE(S)

3

CUTTING HEIGHT RANGE

1″ – 4″

DECK CONSTRUCTION

Fabricated

DECK CUTTING WIDTH

54 in

DECK ENGAGEMENT (PTO)

Electric

DECK LIFT

Manual

DECK MATERIAL

11-gauge steel

DECK POSITIONS

12

DECK WASH

Yes

 Comfort

ARMRESTS

Yes

FLOOR MATS

Rubber

SEAT ADJUSTMENT

Lever

SEAT TYPE

15″ High-back

 Battery

BATTERY

230 CCA

BATTERY TYPE

AGM (Absorbent Glass Mat)

BATTERY VOLTAGE

12V

 Wheels

BEARING TYPE

Ball Bearing

FRONT TIRES

16″x 6.5″-8″

REAR TIRES

22″x 9.5″-12″

TIRE TREAD

Turf Saver

 Controls

BRAKES

Disc

CRUISE CONTROL

Yes

 Chassis

BUMPER

Brush guard

CORROSION PROTECTION

Yes

FRAME

Robotically welded

FRONT PIVOT BAR

Cast iron

REAR TOW HITCH

Yes

TURNING RADIUS

16″

 Warranty

COMMERCIAL WARRANTY

No

DECK SHELL WARRANTY

Lifetime limited

FRAME WARRANTY

5-year limited

FRONT AXLE WARRANTY

5-year / unlimited hour

WARRANTY

3-year Unlimited Hours (Includes Powertrain)

 Additional Specifications

CUP HOLDER

Yes

HEADLIGHT(S)

Dual LED

MODEL NUMBER

14AHA6TMA10

MULCH KIT

Available separately

OPERATOR PRESENCE SYSTEM

Yes

 Disclaimer

SPECIFICATIONS DISCLAIMER

Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.

 Drive System

DRIVE SYSTEM

Hydrostatic

ENGINE TO TRANSMISSION

Heavy-duty belt

FORWARD SPEED

5.5 MPH / 8.6 KMH

REAR AXLE

1″

REAR DIFFERENTIAL LOCK

Yes

REVERSE SPEED

3 MPH / 4.8 KMH

TRANSMISSION

Tuff Torq® K62

TRANSMISSION CONTROL

Foot Pedal

TRANSMISSION HOUSING

Cast aluminum

 Specifications

SERIES

XT2® Enduro Series”
